    Professional Extrusion tube Cleart Silicone Rubber Tube Manufacturer

    Ask Lasest Price
    Brand Name : SUNBOW
    Model Number : SB-SRT
    Certification : UL, ROHS, REACH
    Price : USD0.012-USD3.0/meter
    Payment Terms : TT, paypal
    Supply Ability : 9,000,000meters/month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Professional Extrusion tube Cleart Silicone Rubber Tube Manufacturer

    Professional Extrusion tube Cleart Silicone Rubber Tube Manufacturer

    Model Number:SB-SRT
    Operating temperature: -60ºC ~ +200ºC

    STRUCTURE
    It is extruded by silicone rubber.

    USAGE
    Silicone Rubber Tubing with service temperature -30℃ to 250℃. They are commonly used in contact with foods in accordance with provisions of FDA 21 CFR 177.2600 and in electric insulation. It can be installed in Coffee maker, electric water bottle, or used in electric insulation etc.

    SPECIFICATION

    PerformanceTest methodPerformance index
    Dielectric strength(kv/mm)GB/T 1048≥18
    Volume resistivity(Ω/cm)GB/T 1410≥1x1014
    Tearing strength(MPa)GB/T 1040≥3.5 MPa
    Elongation(%)GB/T 1040≥210
    Fire resistance(flame retarded products)GB/T 2408FV-1



    DIMENSION

    SIZETolerance(mm)Thickness and tolerance
    2500V(mm)4000V(mm)6000V(mm)7000V(mm)
    φ0.80.8±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ1.01.0±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ1.51.5±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ2.02.0±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ2.52.5±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ3.03.0±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ3.53.5±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ4.04.0±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ4.54.5±0.100.50±0.101.00±0.151.50±0.202.00±0.25
    φ5.05.0±0.200.50±0.101.00±0.151.50±0.202.00±0.25
    φ5.55.5±0.200.50±0.101.00±0.151.50±0.202.00±0.25
    φ6.06.0±0.200.50±0.101.00±0.151.50±0.202.00±0.25
    φ6.56.5±0.200.50±0.101.00±0.151.50±0.202.00±0.25
    φ7.07.0±0.201.00±0.151.50±0.202.00±0.25
    φ7.57.5±0.201.00±0.151.50±0.202.00±0.25
    φ8.08.0±0.251.00±0.151.50±0.202.00±0.25

    φ9.09.0±0.251.00±0.151.50±0.202.00±0.25
    φ10.010.0±0.251.00±0.151.50±0.202.00±0.25
    φ11.011.0±0.301.00±0.151.50±0.202.00±0.25
    φ12.012.0±0.301.00±0.151.50±0.202.00±0.25
    φ13.013.0±0.301.00±0.151.50±0.202.00±0.25
    φ14.014.0±0.301.50±0.202.00±0.25
    φ15.015.0±0.301.50±0.202.00±0.25
    φ20.020.0±0.302.50±0.3

    Remark: Other sizes can be made upon customer requirements.
    COLOR: Standard color is white, other color available upon request.

    FAQ
    1. Why choose us?
    We are the No.1 fiberglass sleeve coated silicone resin in China.
    2. What material do you use?
    Fiberglass yarn and silicone resin,PVC,silicone,PE,PET. RoHS,Reach,UL certificated
    3. How's the package?
    Packed by roll then rolls by carton. Also can cut and pack as requested.
    4. Where is your factory?
    In Shenzhen. The loading port here is Yantian or Shekou.
    5. How many employees are there in your company?
    More than 50.
    6. How many people are there in your R&D department?
    More than 5 desingers,.
    7. How do you control the quality?
    We have 8 QC team.
    Each process has one QC. We check carefully before shipment.
    8. What's your sample lead time?
    can ship right now if in stock.5 - 7 working days if the items are out of stock.
    9.Is the sample free charge?
    Yes,it is free but the express fee should be paid by buyer.
    10.What's your mass production lead time?
    7 - 15 working days.
    11. What's your payment terms?
    L/C at sight, T/T in advance,Western Union,Paypal.
    Professional Extrusion tube Cleart Silicone Rubber Tube Manufacturer
    Professional Extrusion tube Cleart Silicone Rubber Tube Manufacturer


    USAGE


    .
