    Soft Clear Flexible PVC Tubing PVC Jacketed Sleeves For Wire Harness

    Ask Lasest Price
    Brand Name : SUNBOW
    Model Number : SB-PVC
    Certification : UL, ROHS, REACH
    Price : USD 0.01-0.99/M
    Payment Terms : L/C, T/T, Paypal
    Supply Ability : 2000000 meters/ month
    Delivery Time : 7-10 work days.
    • Product Details
    • Company Profile

    Soft Clear Flexible PVC Tubing PVC Jacketed Sleeves For Wire Harness

    Soft Clear Flexible PVC Tubing PVC Jacketed Sleeves For Wire Harness


    Product Description

    GRADE:SB-PVC
    Working temperature:-30°C~+105°C

    STRUCTURE


    PVC tubing is produced with superior and environmentally friendly polyvinyl colloidal particle, after drying,

    extruded to tubing when heated up and liquated, then packing in rolls after cooling.


    USAGE


    With the excellent flexibility, mechanical and dielectric capability, flame resistance performance, PVC tubing

    is widely used in outside insulation protection of outgoing wires of electrical appliances, transformers, electrical

    motors or lighting equipment, and electronic components, wire harness and etc.


    SPECIFICATION


    ItemUnitTest MethodNumerical Value
    SB-300SB-600
    Voltage ratingV300600
    Temperature rating°CUL224105
    Voltage resistanceBefore agingUL224 23°C2500V/60sec
    After agingUL224 136°C 168hr2500V/60sec
    Volume resistivityΩcmUL224≥1010
    Tensile strengthBefore agingMpaUL224 23°C≥10.4
    After agingMpaUL224 136°C 168hr≥7.3
    ElongationBefore aging%UL224 23°C≥100%
    After aging%UL224 136°C 168hr≥100%
    FlexibilityUL224 136°C 168hrNo cracking
    Heat shockUL224 180°C 4hrNo cracking
    Cold bendUL224 -30°C 1hrNo cracking
    Copper stabilityUL224 136°C 168hrNo corrosion
    Flame resistanceUL224VW-1

    DIMENSION


    Flexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harness


    Flexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harness


    Flexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harness


    Flexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harness

    Flexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harnessFlexible UL224 vw-1 Plastic Tubing PVC jacketed Electric clear sleeve for wire harness


    Our Services


    1) 3~5 quick time production;

    2) 2 years quality guarantee;

    3) Prompt feedback;

    4) 24 hours on line service.


    Company Information

    1) ISO 9001:2008 approved;

    2) 10 years exporting experience;

    3) 15 years manufacturing experience;

    4) Other products certificates: UL E360625 for heat shrink tube, silicone rubber tube and PTFE tube; E333178 and E333177 for silicone fiberglass sleeve; ROHS, REACH, CQC.
