Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor

    Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers

    Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers
    • Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers
    • Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers
    • Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers
    • Buy cheap Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor from wholesalers

    Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor

    Ask Lasest Price
    Brand Name : Sunbow
    Model Number : SB-PET-HST
    Certification : UL, ROHS, REACH
    Price : USD0.12-USD3/meter
    Payment Terms : TT, LC, WU, paypal
    Supply Ability : 9,000,000meters/month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor

    Non-flammable PET heat shrink sleeving special tubes for soldering, connection, wire harness, motor and cable


    Model Number:SB-PET-HST

    Operating temperature: -60ºC ~ +150ºC


    Clear PET Heat Shrink Sleeving Special Tubes for Soldering , Connection , Wire Harness , AC motor

    Structure

    PET heat shrink tubing is manufactured by twisted polyester film then adhesives by special glue. The glue possesses similar chemical characteristics with polyester film.


    Usage

    Main application range: insulation and mechanical protection for soldering, connection, wire harness, transformer, motor, cable, heating element, capacitor, telephone, electrical appliance etc.



    Characteristics

    Dimension

    Inside diameter2.0-65(mm),Thickness 0.05-1 (mm), Length10-1000(mm)

    Color

    Clarity, light yellow, haze , stripe

    Melting point

    250ºC -265ºC

    Service temperature

    -70ºC~150ºC

    Dielectric strength

    2650V/MIL25ºC 60CYCLE 2125V/MIL150ºC 60CYCLE

    Water absorption

    75% max after 24 hr immersion

    Corrosive on Copper

    Negligible

    Solubility in acid, oil, paint, industrial solvents tec.

    Undissolved

    Antibacterial, anti corrosive

    Excellent

    Tenacity

    Excellent

    Cuticle intensity

    400g/cm2 (MIN)

    Resistance pressure

    50HZ 2500V/min Not perforative

    Visual

    Smooth, No fleck & Eye winker

    Style

    Polyester

    Heat shrink polyester

    Slow shrink polyester

    Not flammable polyester

    Shrinkage (Diameter)

    ≤2

    32%

    8-12%

    ≤2%

    Shrinkage (Length)

    ≤2

    35%

    8-12%

    ≤2%

    Flammability

    Slow to self-extinguishing

    Burning resistance

    Resistance characteristics

    Resistance to abrasion, acids, immersion, mildew, industrial solvent, mechanical destroy, Freon and special liquids

    Xylene extraction

    <2%

    Environment protection

    No hurtful to human and environment


    Note: Besides above dimension, can manufacture other dimension upon request.


    Competitive Advantage:


    1. Great production ability as high as 9,000,000 meters/month
    2. Competitive price with quality products
    3. Standard Flat sizewith 0.5mm-76mm, up to 140mm can be customized
    4. Sunbow design and manufacture
    5. Soft and flexible
    6. Four kinds of shrinkages available
    7. Excellent non-flammability
    8. No harmful to human
    9. Excellent dielectric strength
    10. Smooth surface
    11. Wide application
    12. Anti corrosion
    13. Free samples are avaible
    14. Fast delivery
    15. Sufficient storage
