Brand Name : | Sunbow |
Model Number : | SB-SGS-70 |
Certification : | UL , RoHS , Reach , CSA |
Price : | USD0.07-13.4 per meter |
Payment Terms : | T/T, Western Union, L/C |
Supply Ability : | 600000 Meters / Month |
Delivery Time : | 7~10 Working Days |
Silicone Rubber Braided Fiberglass Sleeving Silicone Rubber Coated Fiberglass Sleeving
Silicone Coated Fiberglass Sleeving Features:
Silicone Coated Fiberglass Sleeving Applications:
Silicone Coated Fiberglass Sleeving may be used for the insulation of leads and connections in transformers.
Silicone Coated Fiberglass Sleeving Properties:
Operating Temperatures: 200°C
Voltage Rating: 600 Volt
Heat Aging: 168 hours at 265°C Without Dielectric Change
Flammability: Self-Extinguishing
Dielectric Strength: 7000 Volts
Item | Performance | Note | |
Dielectric Breakdown Voltage KV AC | Minimum Average | ≥7.0 | Before Aging |
Minimum Single Point | ≥5.0 | ||
Minimum Average | ≥3.5 | 6 Hrs* 245±5ºC 245±5ºC 6Hrs Aging | |
Minimum Single Point | ≥2.5 | ||
No Breakdown | / | 1 KV in 2% Salt Water | |
Thermal Endurance | No Indication of Crack | OK | 1440 Hrs* 235±5ºC 235±5ºC 1440Hrs Aging |
Fire Resistance | VW-1 | OK | UL 1441 |
Dimension
Inside Diameter | Wall Thickness (mm) | Standard Package (m/roll) | |
Nominal (mm) | Tolerance (mm) | ||
φ0.5 | +0.2, -0.1 | ≥0.37 | 200 |
φ1.0 | +0.2, -0.1 | ≥0.37 | 200 |
φ1.5 | +0.2, -0.1 | ≥0.37 | 200 |
φ2.0 | +0.2, -0.1 | ≥0.37 | 200 |
φ2.5 | +0.3, -0.1 | ≥0.42 | 200 |
φ3.0 | +0.3, -0.1 | ≥0.42 | 200 |
φ4.0 | +0.3, -0.1 | ≥0.42 | 200 |
φ4.5 | +0.3, -0.1 | ≥0.51 | 100 |
φ5.0 | +0.3, -0.1 | ≥0.51 | 100 |
φ6.0 | +0.3, -0.1 | ≥0.51 | 100 |
φ7.0 | +0.3, -0.1 | ≥0.56 | 100 |
φ8.0 | +0.3, -0.1 | ≥0.56 | 100 |
φ9.0 | +0.3, -0.1 | ≥0.66 | 100 |
φ10.0 | +0.3, -0.1 | ≥0.66 | 100 |
φ12.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ14.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ16.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ18.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ20.0 | +1.0, -1.0 | ≥0.76 | 25 |
φ25.0 | +1.0, -1.0 | ≥0.76 | 25 |
φ30.0 | +1.0, -1.0 | ≥0.76 | 25 |
![]() |
