Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve

    Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers

    Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers
    • Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers
    • Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers
    • Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers
    • Buy cheap Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve from wholesalers

    Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve

    Ask Lasest Price
    Brand Name : Sunbow
    Model Number : SB-AGS-15
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 600000 Meters / Month
    Delivery Time : 3 ~ 7 Working Days
    Certification : ROHS, REACH
    • Product Details
    • Company Profile

    Electrical AC Motor F Class Acrylic Fiberglass Sleeving , Flexible Fiber Glass Braided Sleeve

    0.5mm to 30.0mm Electrical AC Motor F Class Acrylic Coated Fiberglass Sleeve


    1. Model Number: SB-AGS-15


    Working temperature: -40ºC ~ 155ºC


    2. Dimension


    Inside Diameter (mm)

    Minimum Thickness (mm)

    Nominal

    Tolerance

    Class A(4.0KV)

    Class B(2.5KV)

    0.5~2.5

    +0.25, -0.00

    0.38

    0.20

    3.0~4.5

    +0.30, -0.00

    0.45

    0.23

    5.0~6.0

    +0.40, -0.00

    0.45

    0.28

    7.0~9.0

    +0.55, -0.00

    0.50

    0.32

    10.0~14.0

    +0.75, -0.00

    0.60

    0.40

    15.0~25.0

    +0.85, -0.00

    0.64

    0.43


    3. Structure


    0.5mm to 30.0mm Electrical Motor F Class Acrylic Coated Fiberglass Sleeve is braided with superior fiberglass, then coated with acrylic resin and treated in suitable high temperature.


    4. Data Sheet


    Grade

    Heat Resistance

    Avg. Voltage

    Lowest

    Voltage

    Flame

    Resistance

    Insulation

    Performance

    Oil Resistance

    SB-AGS-15

    -40ºC~+155ºC

    1500V

    800V

    Yes

    Yes

    Yes

    (no water resistance)

    SB-AGS-25

    -40ºC~+155ºC

    2500V

    1500V

    Yes

    Yes

    Yes

    (no water resistance)

    SB-AGS-40

    -40ºC~+155ºC

    4000V

    2500V

    Yes

    Yes

    Yes

    (no water resistance)


    5. Usage


    It is widely used in Class F motors, household electrical appliances, electrical heat devices, and special lamps and lanterns for insulation protection.


    6. Package Information


    0.5mm ~ 4.0mm, 200 meters/roll;

    4.5mm ~ 10.0mm, 100 meters/roll;

    12.0mm ~ 18.0mm, 50 meters/roll;

    20.0mm ~ 30.0mm, 25 meters/roll.

    Carton Size 35*35*60cm


    7. Why Us


    1) factory direct sales

    2) best price high quality product

    3) quick delivery time

    4) quick response for feedback

    5) few complaints from customers

    6) more competitive price for VIP customers

    7) ISO 9001 : 2008 TS 16949 standard factory manufacturer

    8) high-tech enterprise in China

    9) with 12-year manufacturing experience

    10) convenient situation near to seaport

    11) flame resistant tube of this type is available

    12) high quality non-alkali fiberglass yarn

    13) free samples are available


    8. Sunbow Company Information


    Shenzhen Sunbow Insulation Materials MFG. Co., Ltd, established in 2003, mainly engaged in the research & development, manufacture and sale of various insulation sleeving. And we had leading R&D engineers, had a batch of advantageous equipment and testing instruments. Now we had excess of 10 independent patents, gained high-tech enterprise in Shenzhen.


    Our main products include fiberglass sleeving, silicone rubber tube, PVC tube, heat shrink tube, PTFE/FEP tube and so on. All our fiberglass sleeving had been obtained the UL and CSA certificates in 2010 (Cert No: E333178--UZIQ2, VW-1 for flame resistance requirement & E333177--UZFT2/8, 200C, 600V for thermal resistance requirement); Our heat shrink tube, silicone rubber tube and PTFE tube had been obtained UL certificate in 2013 (Cert. No. E360625); PVC tube had been obtained the UL certificates In in Apr.2014 (Cert.No.E467953); In May. 2012, our products successfully had been passed CQC test (Certificate No. CQC12134072554). It provides security for domestic and foreign home appliance supplier in Chinese mainland market. Till now, we are the only one fiberglass sleeving manufacturer which obtained UL, CSA, and CQC certificates. Also we are the only one manufacturer which can provide certificates for all color and maximum size range (from 0.55mm to 25.4mm). Also all our products are in conformance with the European RoHS requirements, furthermore, based on European new requirements, we re-applied and obtained German PFOA and PFOS certificates and European Reach report.


    Our products are widely used in H&N Motor, home appliance, electric heating equipment, Lighting, electronic instruments, wiring harness, transformer, power adapter, communication equipment, high/low voltage power distribution complete equipment, petrochemical industry, coal-mining industry, electric system and space flight and aviation area etc.


    Due to business expansion, our factory moved to Gongming street, Guangming New District in Shenzhen. It occupies nearly 10,000 square meters. We successfully passed ISO9001:2008 and TS16949 international quality management system, now ISO14001 system is also pushing.
