SUNBOW UL Approval ID 10MM Silicone Fiberglasss Sleeving White
1. Model Number: SB-SGS-40
Working temperature: 200ºC
2. Structure
SUNBOW UL Approval ID 10MM Silicone Fiberglasss Sleeving White is non-alkali fiberglass braided then coated with silicone resin
and treated in high temperature.
3. Specification
Item | Performance | Note |
Dielectric Breakdown Voltage KV AC | Minimum Average | ≥4.0 | Before Aging |
Minimum Single Point | ≥3.0 |
Minimum Average | ≥3.0 | 6 Hrs* 245±5ºC 245±5ºC 6Hrs Aging |
Minimum Single Point | ≥2.0 |
Thermal Endurance | No Indication of Crack | OK | 6 Hrs* 245±5ºC 245±5ºC 6Hrs Aging |
Fire Resistance | VW-1 | OK | UL 1441 |
4. Usage
SB-SGS-40 sleeving with its good dielectric strength, flexibility and flame
retarding properties make it high performance qualities. It can be
widely used in insulated or partially insulated conductors, bus
bars, component leads, or assemblies of electrical components etc.
5. Dimension
Inside Diameter | Wall Thickness (mm) | Standard Package (m/roll) |
Nominal(mm) | Tolerance(mm) |
φ0.5 | +0.2, -0.1 | ≥0.37 | 200 |
φ1.0 | +0.2, -0.1 | ≥0.37 | 200 |
φ1.5 | +0.2, -0.1 | ≥0.37 | 200 |
φ2.0 | +0.2, -0.1 | ≥0.37 | 200 |
φ2.5 | +0.3, -0.1 | ≥0.42 | 200 |
φ3.0 | +0.3, -0.1 | ≥0.42 | 200 |
φ4.0 | +0.3, -0.1 | ≥0.42 | 200 |
φ4.5 | +0.3, -0.1 | ≥0.51 | 100 |
φ5.0 | +0.3, -0.1 | ≥0.51 | 100 |
φ6.0 | +0.3, -0.1 | ≥0.51 | 100 |
φ7.0 | +0.3, -0.1 | ≥0.56 | 100 |
φ8.0 | +0.3, -0.1 | ≥0.56 | 100 |
φ9.0 | +0.3, -0.1 | ≥0.66 | 100 |
φ10.0 | +0.3, -0.1 | ≥0.66 | 100 |
φ12.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ14.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ16.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ18.0 | +1.0, -1.0 | ≥0.66 | 50 |
φ20.0 | +1.0, -1.0 | ≥0.76 | 25 |
φ25.0 | +1.0, -1.0 | ≥0.76 | 25 |
φ30.0 | +1.0, -1.0 | ≥0.76 | 25 |
6. Package Information
0.5mm ~ 4.0mm, 200 meters/roll;
4.5mm ~ 10.0mm, 100 meters/roll;
12.0mm ~ 18.0mm, 50 meters/roll;
20.0mm ~ 30.0mm, 25 meters/roll.
Carton Size 35cm * 35cm * 60cm
7. Competitive Advantages
1) UL , RoHS , Reach approval
2) high quality non-alkali fiberglass yarn
3) 3KV & 10KV tube of this type can be customized
4) ISO 9001 : 2008 TS 16949 standard factory manufacturer
5) the only factory in China for all sizes and full colors to pass
UL, RoHS, Reach certifications
6) high-tech enterprise in China
7) with 12-year manufacturing experience
8) factory direct sales
9) best price high quality product
10) quick delivery time
11) quick response for feedback
12) few complaints from customers
13) more competitive price for VIP customers
14) convenient situation near to seaport
15) cutting service and special customized service can be available
