    GLASS FIBRE SILICONE WIRE SLEEVING SILICONE FIBERGLASS SLEEVING

    Ask Lasest Price
    Brand Name : SUNBOW
    Model Number : SB-SGS-70
    Certification : UL, CUL, REACH, ROHS, ISO, TS
    Price : USD
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 9,000,000meters/month
    Delivery Time : 7~10 working days
    • Product Details
    • Company Profile

    GLASS FIBRE SILICONE WIRE SLEEVING SILICONE FIBERGLASS SLEEVING

    GLASS FIBRE SILICONE WIRE SLEEVING SILICONE FIBERGLASS SLEEVING


    Max Temperature Rating: 200ºC,

    Max Working Voltage: 600V

    Silicone Rubber Fiberglass Sleeving SB-SGS-70: Non-Alkali Fiberglass Braided, then coated with silicone resin and treated in high temperature.

    Standard Color: White, black, red, yellow, green, brown or rust red or Oxide red, blue, grey etc

    Breakdown Voltage:7.0KV


    Technical Data:

    ItemPerformanceNote
    Dielectric breakdown voltage KV ACMinimum average≥7.0Before aged
    Minimum single point≥5.0
    Minimum average≥3.5

    6 HRS* 245±5ºC

    245±5ºC 6HRS Aging

    Minimum single point≥2.5
    No breakdown/1 KV IN 2% Salt water
    Thermal enduranceNo indication of crackOK

    1440 HRS* 235±5ºC

    235±5ºC 1440HRS Aging

    Fire resistanceVW-1OKUL 1441

    SB-SGS-70 sleeving with its good dielectric strength, flexibility and flame retarding properties make it high performance qualities. It can be widely used in insulated or partially insulated conductors, bus bars, component leads, or assemblies of electrical components etc.


    Inside DiameterWall thickness (mm)Standard package (m/roll)
    Nominal (mm)Tolerance (mm)
    φ0.5+0.2, -0.1≥0.37200
    φ1.0+0.2, -0.1≥0.37200
    φ1.5+0.2, -0.1≥0.37200
    φ2.0+0.2, -0.1≥0.37200
    φ2.5+0.3, -0.1≥0.42200
    φ3.0+0.3, -0.1≥0.42200
    φ4.0+0.3, -0.1≥0.42200
    φ4.5+0.3, -0.1≥0.51100
    φ5.0+0.3, -0.1≥0.51100
    φ6.0+0.3, -0.1≥0.51100
    φ7.0+0.3, -0.1≥0.56100
    φ8.0+0.3, -0.1≥0.56100
    φ9.0+0.3, -0.1≥0.66100
    φ10.0+0.3, -0.1≥0.66100
    φ12.0+1.0, -1.0≥0.6650
    φ14.0+1.0, -1.0≥0.6650
    φ16.0+1.0, -1.0≥0.6650
    φ18.0+1.0, -1.0≥0.6650
    φ20.0+1.0, -1.0≥0.7625
    φ25.0+1.0, -1.0≥0.7625
    φ30.0+1.0, -1.0≥0.76

    25
